SIEDS Multisensor (Smart Industrial Environment Digitalization Sensor)

The SIEDS is an industrial multisensor that combines 10 sensors, onboard data processing, and network communication in a single size-optimized IP65 housing — delivering environmental and condition monitoring data across temperature, pressure, humidity, air quality, vibration, acoustics, and more from a single device. A self-learning teach mode establishes normal operating baselines automatically, enabling the integrated alarm management system to detect and report deviations without requiring manual threshold configuration. Power over Ethernet eliminates the need for a separate power supply, and the integrated 2-port PoE-capable switch allows the SIEDS to be inserted inline into an existing network run without consuming an additional switch port.

Compatible with PROmanage® NT network monitoring software for centralized visibility alongside PROFINET network condition data.

Key Features
10 Sensors in One Device: Simultaneously monitors temperature, pressure, humidity, CO2, VOC (air quality), acceleration, gyroscope, magnetometer, acoustics, and light from a single IP65-rated housing, eliminating the need for multiple sensors from different manufacturers.

Self-Learning Teach Mode: Automatically establishes normal operating baselines through teach-in calibration, enabling the alarm management system to detect deviations from learned conditions without manual threshold configuration.

Integrated Alarm Management: Configurable alarm triggers allow the SIEDS to operate in standalone mode, generating alerts based on sensor deviations without requiring a connected monitoring system for basic alarm functions.

Power over Ethernet: Powered entirely via the network cable connection using PoE, simplifying installation by eliminating separate 24VDC power wiring at the sensor location.

Integrated 2-Port PoE Switch: Built-in switch allows the SIEDS to be installed inline in an existing network segment without requiring a vacant switch port, preserving existing cabling infrastructure.

Open Protocol Interfaces: Supports RestAPI, OPC UA, MQTT, and HTTPS for flexible integration into a wide range of industrial data platforms, SCADA systems, MES, and IIoT architectures.

Integrated Web Server: Real-time sensor data and alarm status accessible via web browser without additional software, supporting quick commissioning and ongoing status checks from any connected device.

M12 D-Coded Network Connection: Industrial-grade M12 connectivity rated for harsh environments, with direct mounting and IP65 protection for deployment on machines, in cabinets, or in production areas.

Common Applications
Condition monitoring of control cabinets and electrical enclosures where temperature, humidity, and vibration trends indicate developing equipment issues before failures occur

Machine health monitoring in production environments where acoustic, vibration, and environmental data support predictive maintenance strategies across multiple assets from a single sensor per location

IIoT and Industry 4.0 digitalization projects requiring standardized sensor data delivery via OPC UA or MQTT to higher-level data platforms without custom integration work

Environmental monitoring in pharmaceutical, food and beverage, and other regulated production environments where temperature, humidity, and air quality data require continuous logging and alerting

Technical Specifications
-Sensors: Temperature, pressure, humidity, CO2, VOC, accelerometer, gyroscope, magnetometer, acoustics, light (10 total)
-Network Connection: M12 D-coded, 100 Mbps
-Power Supply: Power over Ethernet (PoE)
-Integrated Switch: 2-port, PoE-capable
-Protocols: RestAPI, OPC UA, MQTT, HTTPS
-Integrated Web Server: Yes
-Teach Mode: Yes (self-learning)
-Alarm Management: Yes (standalone capable)
-Operating Temperature: -40°C to +70°C
-Protection Rating: IP65
-Mounting: Direct mounting
-Certifications: CE, UKCA
-SKU: 124110000
