PROFINET Connector | RJ45 Fast Connect Plug 90°

The RJ45 Fast Connect Plug 90° is an industrial-grade PROFINET connector for joining PROFINET cables to network components, switches, and end devices in machine and plant environments. The 90° angled outlet reduces cable strain and saves space in tight control cabinet installations where a straight connector would create excessive bend radius or clearance issues. Color-coded insulation displacement contacts simplify termination and allow for a visual wiring check after connection.

Available in a straight (180°) version for installations where cable routing allows a direct exit angle.

Key Features
90° Angled Outlet: Space-saving angled cable exit reduces bend radius requirements and simplifies cable management in dense control cabinet and panel installations.

Fast Connect IDC Termination: Insulation displacement contacts allow quick, tool-assisted termination to IE FC TP PROFINET cable without stripping individual conductors.

Color-Coded Contacts: Contact elements are color-marked to simplify correct wiring and reduce the risk of connection errors during installation or field replacement.

Visual Wiring Check: Connector design allows visual verification of correct contact seating after termination.

Industrial Metal Housing: Rugged metal housing suited for industrial environments with operating temperatures from -20°C to +70°C and protection rating IP20.

Common Applications
Connecting PROFINET cables to controllers, I/O devices, switches, and other network components during system commissioning.

Field termination of PROFINET runs in control cabinets where 90° cable routing improves clearance and organization.

Replacement of damaged or failed field connectors during maintenance without re-pulling cable.

New PROFINET infrastructure installations requiring reliable, standardized RJ45 connectivity up to 100 Mbps.

Technical Specifications
-Outlet Angle: 90°
-Transmission Rate: Max. 100 Mbps (Cat5e)
-Max. Segment Length: 100m
-Connections: 4 x IE FC TP (IDC), 1 x RJ45
-Fast Connect: Yes
-Housing: Industrial metal
-Protection Rating: IP20
-Operating Temperature: -20°C to +70°C
-Storage Temperature: -40°C to +80°C
-Permissible Humidity: Max. 95%
-Dimensions (H x W x D): 43.5 x 40.5 x 16.2 mm
-Weight: Approx. 35g
