EtherNet/IP-INspektor® NT | Diagnostic and monitoring tool for online analysis

The EtherNet/IP-INspektor NT is a permanent network monitoring system that provides 24/7 surveillance of EtherNet/IP communications. Unlike snapshot testing tools that only capture network conditions at specific moments, the INspektor NT continuously monitors network health, automatically detects communication anomalies, and enables predictive maintenance strategies that prevent costly production downtime.

Key Features
Continuous monitoring of EtherNet/IP communication quality and network performance with automatic anomaly detection and alarm generation. The system tracks signal integrity, CIP messaging errors, topology changes, and device diagnostics around the clock without requiring manual intervention.

Storage capacity for up to 2,000 alarm messages with timestamping and detailed event logging. Each alarm includes comprehensive diagnostic information to accelerate troubleshooting and root cause analysis.

Web-based interface accessible from any device on the network, eliminating the need for specialized software installation. Engineers can monitor network health, review alarms, and analyze trends from their desktop or mobile device.

Automatic topology mapping that displays the complete EtherNet/IP network structure including all devices, connections, and port assignments. The topology view updates automatically when network changes occur, maintaining accurate documentation without manual updates.

Multiple alert methods including SNMP traps, email notifications, and relay outputs for integration with plant alarm systems and SCADA platforms. Critical alarms can trigger immediate notifications to maintenance personnel regardless of their location.

DIN-rail mounting for easy installation directly in control cabinets. The compact design requires minimal panel space and integrates seamlessly into existing automation architectures.

Acceptance log generation for commissioning documentation. The system captures baseline network performance during installation, creating a reference point for future diagnostics and validation that the network meets design specifications.

Common Issues Detected
Communication errors and CIP messaging failures that indicate wiring problems, EMI interference, or failing network components before they cause complete system failures. Early detection enables scheduled maintenance during planned downtime rather than emergency repairs during production.

Topology changes that could indicate loose connections, damaged cables, or unauthorized network modifications. Immediate notification of topology changes helps maintain network security and integrity.

Signal quality degradation that warns of developing cable faults, connector issues, or environmental conditions affecting network performance. Trending of signal quality metrics enables predictive replacement of cables and connectors before failures occur.

Device diagnostics including module status, I/O errors, and parameter changes. The system monitors all diagnostic data provided by EtherNet/IP devices and flags abnormal conditions for investigation.

Technical Specifications
-EtherNet/IP scanner and adapter support with full CIP protocol compatibility. Compatible with all standard EtherNet/IP devices from Rockwell Automation, Schneider Electric, Omron, and other manufacturers following ODVA specifications.
-10/100 Mbps Ethernet connection with automatic speed and duplex negotiation. Supports both copper and fiber optic network connections.
-Operating temperature range: 0°C to +60°C for industrial environment deployment.
-Power supply: 24 VDC nominal (18-30 VDC range) for standard industrial control cabinet installation.
-Dimensions: Standard DIN-rail housing for space-efficient mounting.

The EtherNet/IP-INspektor NT transforms network maintenance from reactive troubleshooting to proactive health monitoring, reducing unplanned downtime and maintenance costs while improving overall equipment effectiveness.
