FIVENORM® H05V2-K – Five-Norm PVC Hook-Up Wire

HELUKABEL’s FIVENORM® H05V2-K is a PVC single-conductor hook-up wire designed to simplify global builds. With harmonized HAR, UL AWM/MTW, and CSA TEW/AWM approvals (plus EAC), it lets you use one part family for North American and EU machines and control panels. A finely-stranded class-5 copper core with TI3 PVC insulation provides reliable flexibility and clear color identification.

Key Advantages

• Five-norm compliance (HAR, UL AWM/MTW, CSA TEW/AWM, EAC) for easy export and harmonized BOMs.
• Broad temperature window: fixed −40…+90 °C (UL/CSA up to +105 °C), flexible +5…+90 °C.
• Voltage ratings: 300/500 V (IEC); UL AWM 1000 V DC / 1000 V AC, UL MTW/CSA 600 V.
• Flame-retardant: IEC 60332-1-2 / EN 60332-1-2, UL VW-1, CSA FT1.
• Quality materials: cadmium- and silicone-free; lacquer-wetting neutral.
• Easy wiring: flexible class-5 copper, smooth PVC, and a wide color palette (solid and two-color options).

Technical Highlights

• Conductor: bare copper, class 5 (IEC 60228 / VDE 0295).
• Insulation: PVC TI3 (EN 50363-3 / VDE 0207-363-3).
• Test voltage: 2 kV (spark test: 0.5 mm² = 5 kV; 0.75–1 mm² = 6 kV).
• Minimum bend radius (fixed): 4× outer Ø.
• Approved colors: black, green-yellow, blue, brown, red, white, gray, violet, yellow, green, orange, pink, turquoise, plus two-color combinations.

Applications

Ideal as jumper and hook-up wire in machine tools, control cabinets, switchgear, and equipment wiring. Its multi-standard approvals support exported machines and global OEM panel builds, reducing variants and simplifying inventory.
