GAM Enterprises, Inc. Product

Right Angle Spiral Bevel Gearboxes

Model: V, VC, VP, VPC

GAM Enterprises, Inc.

Image of Right Angle Spiral Bevel Gearboxes

Our V-Series is a great spiral bevel gearbox solution whether for power transmission, high torque, or dynamic applications. These gearboxes feature sturdy cast iron housings, hardened bevel gears that are lapped in pairs, and robust bearings all contributing to a reliable and optimized performance.


  • Readily available in a wide range of frame sizes
  • Many shaft configurations
  • Mathematically precise common bevel gear ratios
  • High efficiencies 94-98%
  • Lubricated for life with synthetic oil

The GAM Spiral Bevel Gearboxes are available with many configurations with single, multiple shaft or hollow shaft configurations:

  • V-Series: sizes 35 mm to 350 mm
  • VC- Series: sizes 35 to 200 mm with integral motor mount

Combining these features with GAM’s ability to customize, the V-Series spiral bevel gearbox will be a perfect addition to your machine design.

VP Performance Plus Miniature Gearboxes

The VP Series Performance Plus miniature spiral bevel gearboxes pack high performance in a small package with the highest torque density, range of ratios, and torque capacity on the market.

  • Highest torque density for the size
  • Sizes 27, 33, and 45 mm
  • More ratios for the size: 1:1 to 4:1
  • High Efficiency 98%
  • Nominal Torque capacity of 1.3 to 16 Nm
  • Smooth hollow output option (33 & 45 mm)
  • High-strength aluminum housing
  • Sealed and lubricated for life with synthetic oil
  • VPC Series with integrated motor mount
  • Ideal for Medical and Semiconductor applications
