FHA-C mini Series

The FHA-C mini Series is a family of extremely compact actuators that deliver high torque with exceptional accuracy and repeatability.  The actuator combines a high precision Harmonic Drive® gear component with a pancake brushless servo motor.  A single turn 14 bit (16384 cpr) gear output encoder has been integrated along with a single turn 14 bit (16384 cpr) motor input encoder providing a true absolute encoder that does not require a battery within 360° of rotation of the output.  Typical multi-turn encoders monitoring the motor input shaft require a battery to store the current position when power is lost to the system; however, the dual absolute encoder overcomes this need.  In other words, No Battery Required. When power is restored the actuator knows its position.

Features include:

• Zero backlash
• Incremental, Absolute or Dual Absolute Encoder
• 24VDC winding
• High-torque/weight and torque/volume ratio
• Optional flex-rated cables with sealed connectors

Information on the FHA-C mini actuator from Harmonic Drive can be viewed at:

https://www.electromate.com/assets/catalog-library/pdfs/harmonic-drive/harmonic-drive-fha-mini-24vdc-specsheet.pdf
