Dynalog, Inc. Product
Member Since 2010
Dynalog, Inc. provides robot cell calibration and robot performance analysis products (software and hardware) to robot manufacturers and robot end-users in North America, Europe, and Asia. Dynalog products allow operators not only to identify a robot cell's signature (including robot Denavit-Hartenberg parameters, compliance parameters, fixture location, etc.); but to also use that signature to filter robot programs (e.g., to perform robot cell cloning, off-line programming and robot maintenance). Dynalog calibration software is also used in robotic flexible measurement systems (FMS), as well as other precision robotic applications, where robot positional accuracy is required. Dynalog robot performance analysis products allow operators to verify robot performance characteristics, both static and dynamic, according to ANSI/RIA and ISO standards, as well as simulation/robot performance according to Ford Robot Model Accuracy Standards.
Product filed under:
Industrial Industrial
The CompuGauge robot measurement and analysis system is a tool for both robot manufacturers and their customers to measure, visualize, and analyse the static and dynamic performance of their robots. The CompuGauge system achieves extraordinary positional accuracy while maintaining the portability and afforability that today's manufacturiing environment requires. The CompuGauge system consists of three modules (1) The On-line Measurement module, (2) the Off-line Viewing module, and (3) the Analysis module. The On-line Meausrement module allows the operator to manually or automatically record the robot's x,y,z position statically as well as dynamically. The Off-line Viewing module offers the ability to visuall inspect the recorded robot positions and paths, and the Analysis module contains a series of tests which can be performed on the recorded data to verify accuracy, repeatability, cornering warm-up drift, etc. These tests include both internationally recognized standards: ISO 8283 and ANSI /RIA R15.05-1/2.
