New Tecnotion QTR65 and QTR78 Series Frameless Torque Motors

Almelo, The Netherlands – Tecnotion introduces a new series of smaller QTR torque motors at the SPS IPC Drives 2017. A new 65 mm and 78 mm diameter motor make the quality and torque of Tecnotion QTR series motor available for even smaller applications.

Central in the development of the new 65 and 78 mm motors is the low axial height and high torque density, known of existing Tecnotion QTR motors. A special rotor design allows for the large inner diameter. This makes it possible to use hollow axles, even for the QTR 65 motor. Four different stator heights are available for each diameter. The small QTR motors therefore suit a wide variety of markets including semiconductor, medical, machine tooling and robotics.

Certified Motion Control Professional Program

Strengthen Your Skills and Enhance Your Career

Motion control is ubiquitous to automation. A3 offers the fundamental knowledge that benefits everyone working with motion control, motors and automation technologies. The program is designed to ensure professionals have the knowledge they need to advance their careers and benefit their businesses.

Become a Certified Motion Control Professional (CMCP) and join the elite group of system integrators, machine builders, manufacturers, end-users and others recognized in the industry for their professional knowledge and expertise.

Become Certified

QTR 65 and QTR 78 motors have a brushless design. No mechanical transmission is needed. Torque ranges from 0.3-2.3 Nm continuous for the QTR 65 and 0.6-4.7 Nm continuous for the QTR 78. Speed ranges from 410-6200 rpm at just 48 volts.

To provide maximum flexibility and integration the QTR 65 and QTR 78 use flying leads instead of a power cable.
