Technosoft is a leading gloval manufacturer of motion control products, offering intelligent OEM drive solutions for universal control of AC servo, Stepper, and CD Motors. All products are fully programmable, enabling distributed control via RS232, RS485, CANopen, and EtherCAT networks. A full compliment of software tools, including EasyMotion Studio and host level libraries are offered to speed development of motion and machine control applications.
Product filed under:
Controls Controls
- Sinusoidal (FOC) or trapezoidal (Hall-based) control of brushless motors
- Open-loop or closed-loop control of 2-phase and 3-phase steppers
- Position, speed and torque control
- Motion modes: position and speed profiles; PVT & PT interpolated, electronic gearing and cam, cyclic synchronous position, speed and torque
- Motion programming via TML (Technosoft Motion Language)
- Independent execution of complex motion functions stored in the drive memory
- Communication:
- RS-232, up to 115200 baud rate, for setup
- EtherCAT with CoE protocol
- Digital and analog I/Os:
- 4 digital inputs: 5-36 V, NPN/PNP programmable
- 4 digital outputs: 5-36 V, 0.5 A, NPN open-collector
- 2 analog inputs: 12-bit, 0-5 V
- Safety: 2 Safe Torque Off (STO) inputs, Cat. 3 (EN954-1), SIL3 (IEC61508, IEC 62061), PLe (EN/ISO 13849-1)
- Feedback devices (dual-loop supported):
1st Feedback:- Incremental quad encoder, RS-422 differential (BX & BA models)
- Sine/cosine incremental encoder, 1 Vpp differential (BX & BA models)
- Digital Hall sensors (BX & BA models)
- Resolver (BR model)
- Incremental quad encoder, RS-422 differential (all models)
- Sine/cosine incremental encoder, 1 Vpp differential (BA model)
- SSI, BiSS, EnDAT, Hiperface, Absolute A encoders (BA model)
- Protections: over-current, short-circuit, earth fault, over- / under-voltage, I2t, control error
