Motionnet_Nu Servo Drive_Micro Step_5-phase_STP-M510A
Model: STP-M510A
Feature
Compatible with most leading masters like ACS, Beckhoff, Omron, Keyence, Panasonic and many more.
- Motionnet® 5-phase micro-step drive
- STP-M510A : Current 0.75A
- STP-M511A : Current 1.4A
- Constant-current Driving System
- Adjustable running current and stop current
- Support Multiple Resolution (1 ~ 125,000)
- Support 0.36° and 0.72°step angle
- Support Encoder feedback
- Low Vibration and Noise
- DIP switch for address setting
- Dimensions : L-75 x W-140 x H-30 mm
Specification:
| Motionnet | |
| Communication controller | Motionnet slave motion controller ASIC |
| Serial interface | RS-485 with transformer isolation |
| Cable type | CAT5 UTP/STP Ethernet cable |
| Transmission speed | 2.5Mbps, 5Mbps, 10Mbps and 20Mbps |
| Multi Axes Drive | Max. 32 Slaves/Ring |
| 5 Phase Driver | |
| Drive model | 5-phase Constant-current |
| Motor Type | 5-phase 0.36° and 0.72° step angle |
| Micro step | 1, 2, 5, 10, 25, 50, 250, 3, 4, 6, 12, 24, 36 and 72 |
| Driving Current Setting | STP-K510A – Max. 0.75A
STP-K511A – Max. 1.4A RUN: 0~F by rotary switch STOP: 0~F by rotary switch |
| Resolution | 500 1,000 ~ 125,000 pulse/revolution |
| I/O input signal | PEL, MEL, ORG, EMG and LTC |
| I/O output signal | CMP, DO(for brakes, 250mA) |
| Position control | Incremental / Absolute mode, Data range 32bits |
| LED indicator | PWR, RUN, ERR, PEL, MEL, ORG, INP, SVON, ALM, EMG |
| Software | Motion library (DLL) for Win XP/7/10 |
| Input voltage | 24 VDC±10% for main power.
I/O isolated interface requires 24 VDC±10% |
| Current consumption | 3.1W typical (130mA/24V) no load |
| Working temperature | 0°C~50°C (32°F~122°F) ambient temperature with air flow |
| Storage temperature | -20°C~80°C (-4°F~176°F) |
| Humidity | 85% (non-condensing @60°C) |
