Motionnet_Analog Slave(AIO)_108-A222(8-CH.AI/4-CH.AO)
Model: 108-A222(8-CH.AI/4-CH.AO)
Features:
- Max. 20Mbps transfer rate
- Easy installation with RJ45 phone jack and LED diagnosis
- Connectors with screw terminal block
- DIN rail mounting(L-77 x W-124 x H-34 mm)
Specification:
| Motionnet | |
| Serial interface | Half duplex RS-485 with transformer isolation |
| Cable type | CAT5 UTP/STP Ethernet cable |
| Surge protection | 10KV |
| Transmission speed | 2.5Mbps, 5Mbps, 10Mbps and 20Mbps |
| I/O isolation voltage | 3750Vrms |
| DAC Converter | |
| Effective resolution | 12 bits |
| Input impedance | 20MΩ |
| Input range | 0~10V,4~20mA |
| Output impedance | 0.3Ω |
| Output range | 0~10V |
| Sample rate | 10ms/ch. |
| Fault and over-voltage protection | Up to ±12V |
| Accuracy | ±2LBS(INL) / ±0.2LBS(DNL) |
| Zero Drift (ADC) | ±0.2uV/°C |
| Span Drift (ADC) | ±0.5ppm/°C |
| Zero Drift (DAC) | -0.5 ppm/°C (25°C ~ 125°C) |
| Span Drift (DAC) | -3ppm/°C |
| General | |
| Power input | 18VDC to 36VDC |
| Power consumption | 3W typical |
| Working temperature | 0 to 60°C |
