End of Arm Tooling and Tool Changers End of Arm Tooling and Tool Changers
A pneumatic tool changing system improves your application's versatility, efficiency, cycle time, and process reliability. Grippers, tools, and other end-effectors are changed quickly with the help of automated tool changing systems.
Automatic exchange of the end effector (e.g. gripper, pallets, vacuum gripping systems, pneumatically or electrically driven tools, welding guns, etc.) increases the flexibility of your robot.
The quick-change system (SWS) consists of a quick-change master (SWK) and a quick-change adapter (SWA). The SWK is mounted onto the robot, and couples the SWA mounted onto your tool. A pneumatically driven locking piston, with its patented design, ensures that the connection is secure. After coupling, pneumatic and electric feed-throughs automatically supply your robot tool.
Advantages – Your benefits
- Complete series of 14 sizes
for optimal size selection and a broad application range - Patented fail-safe locking mechanism
for secure connection between the quick-change master and adapter - Manual emergency unlocking possible
no counter-forces from springs - All functional components made from hardened steel
for high mechanical resilience of the changing system - Wide range of electric, pneumatic, and fluid modules
for universal energy transmission possibilities - Integrated pneumatic feed-through
for a safe power supply of the handling modules and tools - Possibility of transmission of fluid systems
with self-sealing couplings possible - Adapter side coding
via plug connector possible - Suitable storage racks for all sizes
to ensure the optimum adaption to each application - ISO mounting pattern
for easy assembly to most types of robots without needing additional adapter plates
You can find more information on our homepage.
