Photoneo, Inc. Product
Photoneo is a leading provider of robotic vision and intelligence. Based on a patented 3D technology, Photoneo developed the world’s highest-resolution and highest-accuracy 3D camera, thus unlocking the full potential of powerful, reliable, and fast machine learning.
Product filed under:
Sensors & Feedback Devices Sensors & Feedback Devices
PhoXi 3D Scanners are award-winning 3D scanners for scanning static scenes. They provide high resolution, speed and unbeatable performance in terms of noise and overall efficiency. The PhoXi 3D Scanner provides 3.2 million 3D points in every scan. The scans are provided four times per second. Laser projection guarantees a long depth of field. The projection is focused from 1 m up to 3 m. No linear axes are needed. Thanks to its lightweight carbon fiber body it is possible to mount the scanner on a robotic arm, where every gram counts. The total weight of the device is approximately 1 kg. The PhoXi Scanner provides normal vectors per pixel. The PhoXi 3D Scanner family consists of 5 models (XS - XL). Each one is suitable for different applications, depending on the size of the scanned object and the scanning volume. The Scanners use class 3R visible red light (638 nm) laser projection (models M, L, XL also 2R) and NVIDIA Maxwell GPUs, while offering scanning times of 250 to 2000 ms (XS model), 250 to 2250 ms (S model), 250 to 2500 ms (M model), 250 to 2750 ms (L model), and 250 to 3000 ms (XL model).
