Two New COM Express® Type 2 Modules with Latest Intel® Processors
rong>New support for existing COM Express Type2 install base to upgrade performance at minimum cost
San Jose, CA - ADLINK Technology, a leading global provider of embedded building blocks for edge devices, intelligent services, and cloud-based services that enable the Internet of Things (IoT), today announced the release of its newest COM Express® Type 2 modules. The new products come in two series, Express-HL2 and cExpress-BT2, indicating the 4th generation Intel® Core™ processor and latest Intel® Atom™ system-on-chip. The range in footprint and computing power of these new modules meets the varying needs of industrial applications in a cost-efficient manner.
Type 2 is an earlier COM Express pin-out and is most commonly used in areas such as industrial automation and transportation. As many older generation COM Express Type 2 modules near end-of-life status, ADLINK’s Type 2 modules based on new Intel silicon will serve as a drop-in replacement to extend the service life of Type 2-based systems for another seven years—with continued technical support from both ADLINK and Intel®.
“ADLINK is dedicated to exploring new form factors and technologies, but we also see the value in supporting and enhancing popular, existing form factors so that our customers and end-users can get the most out of their established installations,” said Henk van Bremen, director of ADLINK’s Module Computing Product Segment. “At present, ADLINK is the only company in the market that provides Type 2 modules with both 4th generation Intel® Core™ and the latest Intel® Atom™ processors. ADLINK continues to support COM Express Type 2 so that our customers can upgrade their systems using existing designs without the need to redesign their carrier boards, providing them maximum benefit from their investment.”
The ADLINK Express-HL2 series is a basic size module (125 x 95mm) and is available in high performance SKUs running 4th generation Intel® Core™ i7/i5/i3 processors with Mobile Intel® QM87 Chipset and cost-effective SKUs running Intel® Celeron® processors with Mobile Intel® HM86 Chipset. Up to 16GB dual channel DDR3L at 1600MHz is supported, and dual channel LVDS and VGA supporting two independent displays allow for development of rich video applications.
The cExpress-BT2 series is a compact size module (95 x 95mm), featuring an Intel® Atom™ processor E3800 series or Celeron® processor with a power envelope below 10W and is suitable for small-size and low power consumption applications. The module provides rich I/O including two PCIe x 1 Gen2, 32-bit PCI 2.3, one SATA 3Gb/s port and one PATA IDE port (optional 2 SATA) to meet peripheral expansion needs.
These new Type 2 modules are reinforced by ADLINK’s complete set of technical and engineering tools, including the COM Express Type 2 Starter Kit, which allows system integrators to accelerate carrier board design and software verification; a debug module for POST, BIOS, and Board Management Controller; and Smart Embedded Management Agent (SEMA), which allows users to administer remote monitoring and control tasks via user-friendly graphic interfaces and access state-of-the-art cloud services. Versatile OS support is also provided to deliver flexibility, with standard support for Windows and Linux (32 and 64–bit) and extended support for WES 7/8, WEC 7/8 and VxWorks.
For more information for Express-HL2 and cExpress-BT2 , please visit: http://www.adlinktech.com/Computer-on-Module/Com-Express
ADLINK Technology is enabling the Internet of Things (IoT) with innovative embedded computing solutions for edge devices, intelligent gateways and cloud services. ADLINK’s products are application-ready for industrial automation, communications, medical, defense, transportation, and infotainment industries. Our product range includes motherboards, blades, chassis, modules, and systems based on industry standard form factors, as well as an extensive line of test & measurement products and smart touch computers, displays and handhelds that support the global transition to always connected systems. Many products are Extreme Rugged™, supporting extended temperature ranges, shock and vibration.
ADLINK is a Premier Member of the Intel® Internet of Things Solutions Alliance and is active in several standards organizations, including PCI Industrial Computer Manufacturers Group (PICMG), PXI Systems Alliance (PXISA), and Standardization Group for Embedded Technologies (SGeT).
ADLINK is a global company with headquarters in Taiwan and manufacturing in Taiwan and China; R&D and integration in Taiwan, China, the US, and Germany; and an extensive network of worldwide sales and support offices. ADLINK is ISO-9001, ISO-14001, ISO-13485 and TL9000 certified and is publicly traded on the TAIEX Taiwan Stock Exchange (stock code: 6166).
Intel, Core, Atom, and Celeron are registered trademarks of Intel Corporation in the United States and other countries. All other trademarks are the property of their respective company.
