TI Collaborates with HEIDENHAIN to Incorporate EnDat Interface in the Industry’s First Industrial Drive Control System-on-Chip (SoC)
POSTED 05/31/2017
SCHAUMBURG, IL – HEIDENHAIN CORPORATION is pleased to work with Texas Instruments (TI) in the development of the semiconductor industry’s first microcontroller (MCU) utilizing the HEIDENHAIN EnDat 2.2 interface as an option. TI’s C2000TM MCU industrial drive control System-on-Chip (SoC) delivers a complete solution with a direct connection for industrial motor and servo drives, supporting both analog and digital position sensors.
When combined with TI’s DesignDRIVE Position Manager, this new solution eliminates the complexities of position sensor management in the industrial drive development cycle, saving ancillary components, development time and system cost. Common applications include use in industrial inverter and servo drives for robotics, CNCs, elevators, material conveyance, transportation, and other industrial manufacturing applications.
TI’s MCU system solution improves machine performance by completing decode tasks on-chip, reducing the communication latency and enabling faster control loop performance. In addition, it allows developers to decrease system cost by reducing the board area required in FPGA or ASIC-based solutions.
TI is the only semiconductor vendor that supports both digital and analog position sensors for industrial applications. TI worked with HEIDENHAIN to test this on-chip solution to ensure compatibility. “We approve of TI’s successful implementation and testing of Position Manager to our EnDat specifications,” said Herbert Reiter, HEIDENHAIN’s Senior Product Manager, “and we look forward to working with TI as they enable new EnDat capabilities for our customers.”
HEIDENHAIN’s EnDat 2.2 interface is well known as a digital, bidirectional interface for encoders. It is capable both of transmitting position values from incremental and absolute encoders as well as transmitting or updating information stored in the encoder, or saving new information.
About Texas Instruments
TI is a global semiconductor design and manufacturing company that develops analog ICs and embedded processors.
About HEIDENHAIN
HEIDENHAIN CORPORATION is the North American subsidiary of DR. JOHANNES HEIDENHAIN GmbH, a leading international manufacturer of precision measurement and control equipment based in Tranreut, Germany. The product line includes linear scales, rotary and angular encoders, digital readouts, digital length gauges, CNC controls, and machine inspection equipment. Learn more at www.heidenhain.us.
