PCIe-2602 Dual Channel 3G-SDI Video/Audio Capture Card

POSTED 07/31/2013

rong>Uncompressed video streaming with lossless YUV 4:4:4 color format and up to 12-bit pixel depth; ideal for medical imaging and intelligent video surveillance and analytics

SAN JOSE, CA – ADLINK Technology announces the release of its first SDI video/audio capture card, the PCIe-2602. Based on the PCI Express x4 interface, unparalleled features enable 2-channel acquisition of 3G-SDI for low latency and uncompressed video data signals up to 1920x1080p/60fps, PCIe-2602 Dual Channel 3G-SDI Video/Audio Capture Cardproviding lossless full color 4:4:4 video and up to 12-bit video data for critical applications such as medical imaging, intelligent video surveillance and analytics, and broadcasting.

Unparalleled Performance
ADLINK’s PCIe-2602 supports all SD/HD/3G-SDI signals, and operates at six times the resolution of regular VGA connections. PCIe-2602 also provides unrivaled video quality with lossless full color YUV 4:4:4 images, for sharper and cleaner images. With up to 12-bit pixel depth, the PCIe-2602’s extreme image clarity and smoother transitions from color to color boost image detail for unprecedented support of high-end critical medical imaging, such as PACS (picture archiving and communication system) endoscopy, as well as broadcasting.

Low Latency, Long Distance Transmission Reduces Cabling Costs
The PCIe-2602 features low latency uncompressed video streaming, CPU offloading, and support for high quality live viewing for video analytics of real-time image acquisition, as required in casino and defense environments. When combined with a suitable 75Ω coaxial cable, PCIe-2602 signals can be transmitted over 100 m, requiring no significant modification of existing analog-based CCTV systems, with employment of existing coaxial cable networks representing significant savings.

“The video surveillance market has been developing for decades, evolving from SD to Full HD image acquisition, from passive evidence collection to interactive real-time alarm and analysis deployment parameters, to our current state of intelligent security and surveillance application,” said Neil Chen, ADLINK's product manager for Digital Imaging. “ADLINK’s PCIe-2602 3G-SDI video/audio capture card provides high resolution 1920x1080p/60fps imaging with low latency and uncompressed video streaming, perfectly matching the need for real-time video surveillance and analytics.”

The PCIe-2602 is equipped with RS-485 and digital input & output—accommodating external devices such as PTZ cameras and sensors—supports Windows 7/XP operating systems, and comes with ADLINK’s ViewCreator Pro™ utility to enable setup, configuration, testing, and system debugging without requiring any software programming. All ADLINK drivers are compatible with Microsoft DirectShow, reducing engineering efforts and accelerating time to market.

Key PCIe-2602 Features
–    Support for 2-CH 3G-SDI video, up to 1920 x 1080P/60fps video streaming
–    Low latency, uncompressed video signal
–    High accuracy color format support, 12 bit 4:4:4 1080i/60fps or 10 bit 4:2:2 1080P/60fps
–    Cabling distances up to 100m (w/ compatible 75Ω coaxial cable) supported
–    DirectShow support
–    RS-485 and digital I/O provided

Learn more about ADLINK vision products at www.adlinktech.com /Vision/index.php.

About ADLINK Technology
ADLINK Technology provides a wide range of embedded computing products and services to the test & measurement, automation & process control, communications, medical, defense, and transportation industries. ADLINK products include PCI Express-based data acquisition and I/O; vision and motion control; and AdvancedTCA, CompactPCI, and computer-on-modules (COMs) for industrial computing. With the acquisition of Ampro Computers, Inc. and LiPPERT Embedded Computers GmbH, ADLINK also provides a wide range of rugged by design Extreme Rugged™ and Rugged product lines including single board computers, COMs and systems.

ADLINK strives to minimize the total cost of ownership (TCO) of its customers by providing customization and system integration services, maintaining low manufacturing costs, and extending the lifecycle of its products. ADLINK is a global company with headquarters and manufacturing in Taiwan; R&D and integration in Taiwan, China, the US, and Germany; and an extensive network of worldwide sales and support offices.

ADLINK is ISO-9001, ISO-14001, ISO-13485 and TL9000 certified, is an Associate Member of the Intel® Intelligent System Alliance, an Executive Member of PICMG, a Sponsor Member of the PXI Systems Alliance, an Executive Member of PC/104 Consortium, a Strategic Member of the AXIe Consortium, and a member of VMEbus International Trade Association (VITA). ADLINK is a publicly traded company listed on the TAIEX Taiwan Stock Exchange (stock code: 6166).
