Detailed Resolution Specification Downloadable Files Streamline OEM Integration

POSTED 07/13/2012

Ideal for Building and Specifying Imaging Systems

Barrington, N.J. - Edmund Optics® (EO), the premier provider of optical components, announced today the addition of downloadable engineering files with integration specifications for their most popular lines of TECHSPEC® Imaging Optics. These new downloadable files provide instant access to key specifications for Detailed Resolution Specification Downloadable Files Streamline OEM Integrationbuilding and optimizing imaging systems, which include optical curves, critical decision making data used as a guide in selecting the best lens for the application.

EO's TECHSPEC Integration Specifications are available for the following TECHSPEC lens families: Compact Fixed Focal Length, Silver Series Telecentric, Compact Telecentric, Gold Series Telecentric and High Resolution 5 Megapixel Telecentric. These specifications include graphical curves for Modulation Transfer Function (lens contrast vs. resolution), Depth of Field (contrast vs. working distance), Relative Illumination (brightness from the center to the corner of the image) and Distortion (vs. Image Height.) A detailed schematic drawing, complete with measured dimensions of each lens is also included, as well as tables that include focal length, Field of View range, working distance and aperture (f/#).

"This detailed information, is presented in a complete and easy to understand format. It gives you multiple data points, allowing you the flexibility to select what's specifically most important to your imaging system," said Nicholas James, EO Product Line Manager.

Ideal for OEM Integration

For example, TECHSPEC Compact Fixed Focal Length Lenses include Integration Specifications for each of the seven different focal length models, including the four curves, the drawing with measurements and other detailed specifications.

Added James, "This is ideal for OEM integration - with all of the detailed performance information available for comparison, it's almost like having the lens in front of you when designing your system!"

EO Imaging Experts are available to help

EO is ready to assist with imaging lens selection for your application. In addition to the wide selection of standard lens options, custom designs are also available. Contact us to discuss your requirements with an imaging expert. TECHSPEC Imaging lenses are in-stock and available for immediate delivery for fast turnaround and excellent value.

About EO:

Edmund Optics® (EO) is a leading producer of optics, imaging, and photonics technology for R&D, electronics, semiconductor, pharmaceutical, biomedical, and military markets around the globe. EO is the world's largest supplier of off-the-shelf optical components. Customers can purchase items by contacting EO at 1-800-363-1992, via the catalog, or via the website.

Company Contact:
Kirsten Bjork-Jones
Director Global Marketing Communications
1-800-363-1992
