BitFlow Predicts 2014 will be "Year of CoaXPress"
POSTED 01/16/2014
WOB
"The influx of CoaXPress is largely to address the higher data rates produced by the latest generation of image sensors," explained Donal Waide, Director of Sales & Marketing for BitFlow, Inc. "Sensors with sizes from 12 to 25 Megapixels are coming onto the market capable of delivering up to 2GB of data per second and the camera companies are producing CXP cameras to deal with the data transfer. With its 6.25Gb/s data transfer rate, it caters for these newer, higher-bandwidth cameras. Virtually every major machine vision camera manufacturer has introduced a camera expressly for the CoaXPress interface."
CoaXPress or "CXP" accelerates data transmission rates while providing the ability to be used in long distance cabling applications up to 100 meters. For even higher data rates, multiple CXP channels can be used. For example, the new BitFlow Cyton CXP has four 6.25 Gb/S links providing a total throughput of 25 Gb/S. The back end of the Cyton is based on PCIe x8 Gen 2 DMA engine. This engine can DMA at speeds approaching 4 GB/S. Even at these long distances, CoaXPress permits trigger events to be sent from host to camera and vice versa with minimal latency and jitter.
In addition, because CXP uses low cost, standard 75 Ohm coaxial cable yet delivers impressive bandwidth, it is drawing interest not only from the machine vision community but also from integrators in the medical, military, aerospace, aerial mapping, and security fields where legacy coaxial cable is often deployed. By "re-purposing" already installed coaxial cables, CoaXPress eases the migration from analog to digital cameras.
"Established digital video interfaces such as Camera Link, GigE Vision, USB and FireWire all have limitations and do not meet the requirements of next generation imaging applications," says Waide. "On the high end, Camera Link HS, USB3 and 10 GigE Vision can complete with CoaXPress on some criteria but none have really gained a foothold due to very short maximum cable lengths and other standard specific limitations."
About BitFlow
BitFlow has been developing reliable, high-performance Frame Grabbers for use in imaging applications since 1993. BitFlow is the leader in Camera Link frame grabbers, building the fastest frame grabbers in the world, with the highest camera/frame grabber densities, triggering performance, and price. With thousands of boards installed throughout the world, into hundreds of imaging applications, BitFlow is dedicated to using this knowledge and experience to provide customers with the best possible image acquisition and application development solutions. BitFlow, located in Woburn, MA, has distributors and resellers located all over the world including Asia, Japan, and Europe. Visit our website.
CONTACTS
Donal Waide
BitFlow, Inc.
781-932-2900
Dan O'Connell
O'Connell Communications, Inc.
708-482-0212
