4-CH Simultaneous 16-Bit 2MS/s USB DAQ Module
rong>Leading accuracy and portability make the USB-1210 an ideal solution for high-speed data acquisition
San Jose, CA – ADLINK Technology, a leading global provider of embedded building blocks for edge devices, intelligent services, and cloud-based services that enable the Internet of Things (IoT), today announced the release of its new USB 2.0 data acquisition module, the USB-1210. The USB-1210 supports four 16-bit channels of simultaneous sampling at up to 2 MS/s per channel, and ensures zero data loss in long-term data acquisition by way of 256MS deep onboard FIFO (First In, First Out). The industry’s only 4-CH USB DAQ with simultaneous sampling reaching 2 MS/s supporting USB bus power, the USB-1210 delivers maximum performance with the simplicity and portability of USB connectivity. The result is an optimized solution for portable measurement applications, such as ultrasound and optical sensors.
The ADLINK USB-1210 features high dynamic performance, delivering -100 dB THD and 14.3-Bit ENOB (effective number of bits) at up to 2MS/s. With 256MS deep onboard FIFO, up to 16 sec data buffer enables long-term data acquisition and recording at full speed (2MS/s), preventing data loss from slow CPU response under heavy system loading. In addition, the USB-1210’s built-in precision reference voltage makes auto-calibration simple—with no need for external instruments—reducing the impact of environmental temperature variations to maximize accuracy.
To maintain top performance in varied test environments and conditions, the ADLINK USB-1210 supports external digital/analog trigger source and flexible trigger modes. In addition, 500 VDC isolation protects the connected computer from hazardous voltage caused by improper signal connection, and enhanced anti-noise capability effectively prevents improper ground loop interference, altogether enhancing system reliability.
The ADLINK USB-1210 further provides lockable USB for robust connection and a multi-functional stand that fully supports desktop, rail, or wall mounting. The USB-1210 supports Windows 8 and Windows 7 operating systems and is fully compatible with third-party software such as LabVIEW™, MATLAB®, and Visual Studio.NET®. With ADLINK's free, easy-to-use U-Test software, users can quickly and easily process instrument setup and quality data acquisition with no programming required.
For more information, please visit: http://www.adlinktech.com/DAQ/USBDAQ.php
ADLINK Technology is enabling the Internet of Things (IoT) with innovative embedded computing solutions for edge devices, intelligent gateways and cloud services. ADLINK’s products are application-ready for industrial automation, communications, medical, defense, transportation, and infotainment industries. Our product range includes motherboards, blades, chassis, modules, and systems based on industry standard form factors, as well as an extensive line of test & measurement products and smart touch computers, displays and handhelds that support the global transition to always connected systems. Many products are Extreme Rugged™, supporting extended temperature ranges, shock and vibration.
ADLINK is a Premier Member of the Intel® Internet of Things Solutions Alliance and is active in several standards organizations, including PCI Industrial Computer Manufacturers Group (PICMG), PXI Systems Alliance (PXISA), and Standardization Group for Embedded Technologies (SGeT).
ADLINK is a global company with headquarters in Taiwan and manufacturing in Taiwan and China; R&D and integration in Taiwan, China, the US, and Germany; and an extensive network of worldwide sales and support offices. ADLINK is ISO-9001, ISO-14001, ISO-13485 and TL9000 certified and is publicly traded on the TAIEX Taiwan Stock Exchange (stock code: 6166).
