3rd Generation Intel® Core™ i7 Processor-Based 6U CompactPCI® Blade with Remote Management
POSTED 11/13/2012
SAN JOSE, CA – ADLINK Technology, Inc. (TAIEX: 6166), a leading provider of trusted embedded computing products, announces availability of the cPCI-6520, a 6U single-slot CompactPCI® (CPCI) processor blade designed for use by robust computer makers and intelligent system integrators in mission-critical applications such as those developed for the military sector. With its 22nm 3rd generation quad- and dual-core Intel® Core™ i7 Processor and Mobile Intel® QM77 Express Chipset with dual channel DDR3-1333/1600 ECC memory up to 16GB capacity, the cPCI-6520 delivers tremendous computing power,
massive I/O and memory capacity, and flexible connectivity for robust computing applications requiring server-class performance. The cPCI-6520 is a performance computing solution with enhanced management features such as PICMG 2.9 compliant IPMI, remote management based on Intel® vPro™ technology and optional Trusted Platform Module (TPM) for security management. Wide temperature range support is available up to -40°C to 85°C (operating). The ADLINK cPCI-6520 Series offers oustanding processing and graphics performance for applications requiring reliable, scalable CompactPCI® products with the latest quad-core CPU, 2D/3D graphics engine with multiple displays. Three independent display functionality is provided via two dual-mode DisplayPorts and DVI/VGA graphics interfaces. The DisplayPort interface supports single-link DVI or HDMI with a passive adapter cable and analog VGA output via an active adapter cable. When coupled with a ADLINK XMC-G460 graphics module installed in the XMC site, or an ADLINK cPCI-R6700 Rear Transition Module, the cPCI-6520 Series supports up to four independent displays.
On-card connectivity includes two front panel GbE egress ports, three USB 3.0 ports, bootable CompactFlash socket, on board 7-pin SATA 6Gb/s connector for external storage device and SATA 6Gb/s direct connector for an onboard 2.5” drive to provide flexible storage capabilities. The cPCI-6520 also provides a PMC/XMC expansion site supporting 64-bit 133MHz PCI modules or PCI Express x8 XMC modules. Rear I/O storage interface includes up to three SATA ports with RAID 0/1/5/10 support and up to eight SAS ports supporting hardware RAID by the cPCI-R6200 RTM.
The cPCI-6520 Series can operate in a system slot as a master or in a peripheral slot as a standalone blade for high density computing applications. The cPCI-6520 provides dual channel DDR3-1333/1600 with ECC up to 16GB with one channel soldered onboard up to 8GB and one channel socket up to 8GB. The flexible memory design ensures that the cPCI-6520 is a reliable platform for ruggedized applications. The cPCI-6520 is also validated for reliability in extended temperature conditions ranging from -20°C to 70°C. Select SKUs can support extreme temperatures ranging from -40°C to 85°C with optional conformal coating.
Compatible operating systems for the cPCI-6520 include Windows XP, Windows 7, Fedora 16, Red Hat Enterprise Linux 6.2 and VxWorks 6.9.
About ADLINK
ADLINK Technology provides a wide range of embedded computing products and services to the test & measurement, automation & process control, gaming, communications, medical, network security, and transportation industries. ADLINK products include PCI Express®-based data acquisition and I/O; vision and motion control; and AdvancedTCA, CompactPCI, and Computer-on-Modules (COMs) for industrial computing. With the acquisition of Ampro Computers, Inc., ADLINK also provides a wide range of Extreme Rugged and Rugged Single Board Computers, Computer-on-Modules and Systems under the brand name Ampro by ADLINK.
ADLINK strives to minimize the total cost of ownership (TCO) of its customers by providing customization and system integration services, maintaining low manufacturing costs, and extending the lifecycle of its products. ADLINK is a global company with headquarters and manufacturing in Taiwan; R&D and integration in Taiwan, China, and the US; and an extensive network of worldwide sales and support offices.
ADLINK is ISO-9001, ISO-14001, and TL9000 certified, is an Associate Member of the Intel® Intelligent Systems Alliance, an Executive Member of PICMG, and a Sponsor Member of the PXI Systems Alliance. ADLINK is a publicly traded company listed on the TAIEX Taiwan Stock Exchange (stock code: 6166).
All products and company names listed are trademarks or trade names of their respective companies.
